TS 3000 EC
T-Stop guide rail BG TS 3000 / 5000 * With opening restrictor and lever, opposite hinge side
- Easy to replace with the standard guide rail for opposite hinge side
- Saves time as no floor mounted door stopper needs to be installed
- With screwed sliding block
With opening restrictor and lever, opposite hinge side
Application Areas
- Single leaf doors
- Installation on the opposite hinge side
- Right and left single-action doors
- For opening restriction without door stopper
Technical data
| T-Stop guide rail BG TS 3000 / 5000 | |
| Length | 452.5 mm |
| Width | 33 mm |
| Height | 30 mm |
| Opening restrictor integrated | Yes |
| Hold-open function | Optional |
| Hold-open device can be overridden | Yes |
Downloads
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
