Programme switches

MPS * Mechanical programme switch for setting the mode of operation for automatic doors

Mechanical programme switch MPS-D Programme switch to choose the operating status of automatic doors
  • Available with rotary button or key
Contact us

Mechanical programme switch for setting the mode of operation for automatic doors

Application Areas

  • For changing the modes of operation of GEZE automatic door systems

Technical data

MPS
Dimensions 80 x 80 x 12 mm
Current consumption 50 mA
IP rating IP40
Type of installation Surface-mounted installation, flush-mounted installation
Connection cable length 100 m
Service temperature -15 °C - 50 °C
