Sensor switch
LED sensor foot switch * Switch for activating automatic doors
- Touch-sensitive capacitive push button with blue/red LED illumination
- Long service life - more than 100 million hystereses
- Continuously illuminated blue (can be switched off), illuminated red when touched
- Very high IP rating of 69K
- Shock-resistant and protected from vandalism by protection degree IP08
Switch for activating automatic doors
Application Areas
- For convenient activation of automatic doors from the floor
- Preferred for use in restaurants or hotel areas
Technical data
| LED sensor foot switch | |
| Dimensions | 100 x 100 x 17 mm |
| Current consumption | 30 mA |
| Output | PNP transistor output |
| IP rating | IP69K |
| Type of installation | Floor |
| Cable connection type | Cable prepared for connection to screw terminal |
| Connection cable length | 2000 mm |
| Material | Stainless steel |
| Service temperature | -30 - 80 °C |
Downloads
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
